64 HMX6803+ and OP+HMX+ Installation and Operation Manual
Copyright © 2009, Harris Corporation
Chapter 3: Operation
Table 3-14 describes the specific alarms for the HMX6803+ and OP+HMX+.
You can only identify specific alarms using a software control application.
Table 3-14. Alarm Definitions
Alarm Name
Alarm Option Default Settings
Priority Trigger Clear
Video Standard Mismatch 8 1 sec 2 sec
Unsupported Video Standard 8 1 sec 2 sec
Loss of Electrical SDI Input 9 1 sec 2 sec
Input AES (1A-8B) Silent 1 30.0 s 0.0 s
Input AES (1A-8B) Peak 6 0.0 s 0.0 s
Group (1–4) Append
Embedding Error
6 2 sec 2 sec
Group (1–4) Overwrite
Embedding Error
6 2 sec 2 sec
AES (1–8) In Missing 1 2 sec 2 sec
Output Video Frozen 1 2 sec 2 sec
V-Bit Mute On 4 0.0 s 2.0 s
Master Mute On 5 0.0 s 2.0 s
Laser Failed
(OP+HMX+ modules only)
6 (Major) 1 sec 2 sec
Loss of AFD 5 0 sec 0 sec
