Hasselblad H6D User Manual

H6D www.hasselblad.com
USER GUIDE
To Use
168
CHECK THE BATTERY STATUS
1 On the Sensor Unit Menu Control Screen select the Battery
symbol in the upper right corner.
The Grip Screen displays:
● The rmware version (A).
● The number of captures taken since the last battery
recharge/change (B).
● A rechargeable-battery status icon (C) that provides
a quick visual check as well as a gure estimate in
percent.
Note!
Remember that these are only estimates and that there are a
number of factors affecting remaining battery charge,
ambient temperature for example, as well as general practice.
Note!
You can save battery consumption by changing the Display Off/
Sleep/Power Off settings as well as the brightness settings of
the display.
A
B
C
Battery Level
Low battery warning

Hasselblad H6D Specifications

General

Sensor type	CMOS
Total megapixels	100 MP
Optical sensor size	- \
Optical zoom	- x
Image stabilizer	-
HDMI	No
S-Video in	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
Compatible memory cards	CFast, SD
Internal storage capacity	- GB
Magnification	2.7 x
Camcorder type	Handheld camcorder
Video recording time	- h
Camera shutter speed	1/2000 s
Display diagonal	3 \
Focus adjustment	Auto/Manual
Product color	Black
Video resolutions	1920 x 1080, 3840 x 2160 pixels
Maximum video resolution	11600 x 8700 pixels
Maximum image resolution	- pixels
Operating temperature (T-T)	-10 - 45 °C

Weight and Dimensions

Depth	205 mm
Width	153 mm
Height	131 mm
Weight	2105 g
