Hasselblad H6D User Manual

3.14 SHORT CUTS
1 Menu button – Setting option access. Press MENU button
on the Sensor Unit.
2 Browse button – Starts image browse mode.
3 Shutter release button – Camera activation. Re-activates
camera from Display Off mode. After making any changes, press
EXIT (Menu button) or shutter release button to save the new
setting.
4 Shutter release button – A half press always exits all menus
and returns to shooting mode.
5 Front scroll wheel – Menu navigator / Browser. Functions as
a horizontal navigator on sensor unit menu as well as a capture
browser in Browse mode.
6 Menu button – Toggles the Grip Menu Mode On and Off
When in Menu Mode the wheel is used to navigate the menus of
the Sensor Unit. When not in Menu Mode the wheel controls the
Aperture and Shutter speed. A long press on this button toggles
the camera between video and camera mode.
7 Proles button – Camera activation
Enters Proles menu. Proles will be available in a rmware
update. Re-activates camera from Display Off mode.
8 Rear scroll wheel – Menu navigator
Functions as a vertical navigator on sensor unit menu while in
menu mode. When not in Menu Mode the wheel controls the
Aperture or Shutter speed.
9 True Focus button – Camera activation
Re-activates camera from Display Off mode.
10 True Focus button – Zoom-in button
Automatically acts as Zoom-in button when in Browse mode.
11 True Focus button – Selection button
Automatically acts as value selector on sensor unit
menu when in Menu mode.
12 CFast and SD Card format button – Formats the current
inserted CFast or SD card (requires conrmation).
13 AE-L button – Re-activates camera from Display Off mode.
14 AE-L button – Zoom-out button. Automatically acts as zoom-
in button when in Browse mode.
15 AE-L button – Selection button. Automatically acts as value
selector on sensor unit menu when in Menu mode.
16 Mirror Up button – Camera activation. Re-activates camera
from Display Off mode.
17 Stop Down button – Re-activates camera from Display Off
mode.
1
2
3 4
5
7
6
8
9 10 11
12
13 14 15
16
17
H6D www.hasselblad.com
USER GUIDE
Overview
34

Hasselblad H6D Specifications

General

Sensor type	CMOS
Total megapixels	100 MP
Optical sensor size	- \
Optical zoom	- x
Image stabilizer	-
HDMI	No
S-Video in	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
Compatible memory cards	CFast, SD
Internal storage capacity	- GB
Magnification	2.7 x
Camcorder type	Handheld camcorder
Video recording time	- h
Camera shutter speed	1/2000 s
Display diagonal	3 \
Focus adjustment	Auto/Manual
Product color	Black
Video resolutions	1920 x 1080, 3840 x 2160 pixels
Maximum video resolution	11600 x 8700 pixels
Maximum image resolution	- pixels
Operating temperature (T-T)	-10 - 45 °C

Weight and Dimensions

Depth	205 mm
Width	153 mm
Height	131 mm
Weight	2105 g
