3.4 GRIP BUTTONS AND CONTROLS
Note that some of the buttons have multiple functions according
to the settings made.
1 Shutter release button
This button has two positions. Press half-way (or softly)
to activate the camera, auto focus function and exposure
meter. Press all the way down (or more rmly) to release the
shutter. The chosen exposure procedure and the self timer
are also activated with this button.
2 Front scroll wheel
The front and rear scroll wheels are used to make changes
in exposure settings, provide access to the grip menu for
settings, navigate the sensor unit’s menu as well as acting
as browse controls.
3 WB button / (Control Lock)
This is a triple function button.
Press the button for one second and the beeper will sound
(if set) and a key symbol will appear on the grip display
signifying that the controls (except the shutter release) have
been locked and therefore cannot be altered unintentionally.
Press the button for one second again to unlock.
4 AF button
Press this button to directly access the autofocus/manual
focus selection screen from the main screen. See under
Lenses for full details.
5 ISO
This is a triple function button.
It provides direct access to the ISO settings (see Light
Metering & Exposure Control for full details). A long press
on the ISO button toggles Drive Mode between Single and
Continuous.
6 MENU / Video button
Press this button to activate the Main Menu on the Sensor
Unit Display. A long press activates Video Recording Mode. A
long press again returns to Camera Mode.
7 Browse Mode / Illumination
One click enters Browse mode. Click again to exit Browse
mode. The wheels now controls Aperture/Shutter. A long
press illuminates the display. Remains active until the
camera enters Display Off mode.
8 ON / OFF (Proles) button
Press the button for 1 second to activate the camera. The
H6D start-up logo will appear and then the main screen.
After a few seconds (customizable) the camera will enter
Display Off mode. A long press of the button turns the
camera off completely (even from Display Off mode) signied
by an audible signal (if set). Click on the button to access
the Proles feature (see later section for details).
9 Rear scroll wheel
The scroll wheel is used to make changes in exposure
settings, to provide access to the grip menu for settings, to
navigate the sensor unit’s menu as well as acting as browse
control.
Note!
For the soft buttons 3 to 8 there is a difference between a short
click and a long press. A long press is at least one second. Soft
button 4 does not have any long press function.
1
2
3
4
5
6
7
8
9
H6D www.hasselblad.com
USER GUIDE
Overview
23
