Hasselblad H6D - Remove and Attach the Viewfinder

3.22 REMOVE AND ATTACH THE VIEWFINDER
To remove, hold the viewnder in the right hand and while
pressing the viewnder release button (1), lift the rear of the
viewnder up and away from the camera body (2).
To attach, hold the viewnder at a slight angle and rest it
on the top of the camera. Slide the viewnder forward until
the front locating pin is in position in the recess in the front
edge of the viewnder screen aperture on camera body.
Press the rear part of the viewnder rmly downwards until
it clicks into place.
Ensure that both sides of the viewnder are seated correctly
and that it has been rmly attached and locked into position.
Failure to do so could cause an intermittent malfunction
if the data bus interface connections between the viewnder
and camera body are not positively secured.
Note!
Do not lift or hold the camera by the viewnder alone.
1
2
H6D www.hasselblad.com
USER GUIDE
Overview
43
