DAC-42(A)-x-PN
Page 66
DAC-42(A)-x-PN Manual
Revision: 1.0 22.01.2024
ID
Hex
ID
dec
W/R
Nam
e
Function Unit Min Max Def Description
9 = 7,5 +-5V>
10 = 0..20mA (positive contr. outp. only)
11 = 4..20mA (positive contr. outp. only)
12 = 0..10V (positive contr. outp. only)
13 = reserved
14 = 5V+-3.0V
15..27 = reserved
28 = 5V+
-
2.6V
0x4E
78
R/W
C2.10
Actual value gain
V/V
0
400
100
100 == Factor 1.00
0x4F
79
R/W
C2.11
Actual value offset
V
-
9999
9999
0
-
1000 ==
-
1.000 V; 1000 == 1.000 V
0x50 80 R/W C2.12 Actual value sign --- - 1 + 1 1 - 1 = negative
0 = off
+ 1 = positive
0x51 81 R/W C2.13
P-Portion K
P1
V/V 0 400 0 100 == Factor 1.00
0x52
82
R/W
C2.14
T
-
Portion for PT1 (to C1.16)
S
0
1000
0
100 == 1.00
0x53
83
R/W
C2.15
Threshold (C1.13, C1.16)
V
0
9999
9999
1000 == 1.000 V
0x54 84 R/W C2.16 P-Portion K
P2
V/V 0 400 0 100 == Factor 1.00
0x55
85
R/W
C2.17
I
-
Portion
V/s
0
4000
0
1000 == 1.000
0x56
86
R/W
C2.18
D
-
Portion
Vs
0
400
0
100 == 1.00
0x57
87
R/W
C2.19
T
-
Portion for DT1
S
0
1000
0
100 == 1.00
0x58
88
R/W
C2.20
Gain
(C1.13 and C1.16)
V/V
1
32
1
2 = Factor 2.00
0x59
89
R/W
C2.21
Comparator upper level
V
-
9999
9999
0
-1000 == -1.000 V; 1000 == 1.000 V
0x5A
90
R/W
C2.22
Comparator lower level
V
-
9999
9999
0
0x5B
91
R/W
C2.23
Comparator delay into window
S
0
9999
0
1 == 10 ms
0 == no delay
0x5C
92
R/W
C2.24
Comparator delay out of window
S
0
9999
0
0x5D 93 R/W C2.25 Comparator selection COMP_2 --- 0 3 0 0 = off
1 = Set value
2 = Actual value
3 =Lag error
0x5E
94
R/W
C2.26
Cable fracture detection feedback
---
0
1
0
0 = off; 1 = active
0x5F 95 R E00 Operation mode
(depends on HW + SW version)
--- 1 11 3 1 = Open loop one valve
2 = Open loop two valves
3 = Closed loop one valve
4 = Closed loop on application
6 = Closed loop valve/application
8 = Closed loop application/ application
10 = Controller function only, one feedback
11 = Controller function only, two feedback
0x60 96 R/W E01 Analogue output
(depends on HW + SW version)
--- 1
and
14
13
and
21
1 1 = d1.01 to
13 = d1.13 and
14 = d2.01 to
21 = d2.13
0x61 97 R/W E02 Push-Pull function
(depends on HW + SW version)
--- 0 1 0 0 = off v(no push pull)
1 = active
2 = common “+” for solenoids
(Remark: only for max 0,8 A current )
3 = full bridge
4 = off + detection low current to solenoid
5 = active + detection low current to solenoid
0x62 98 R/W E03
E1.03
Solenoid selection
Solenoid selection A
(depends on HW + SW version)
--- 1 7 6 Standard solenoid definition
1 = 0,8 A
2 = 1,1 A
3 = 1,3 A
4 = 1,6 A
5 = 2,4 A
6 = 2,7 A
7 = 3,5 A
(depends on HW + SW version)
0x63 99 R E04
E1.04
P-Portion current contr. Energization A --- 500 9999 500 Default for 2,700 A solenoid
0x64 100 R E05
E1.05
I-Portion current contr. Energization A --- 500 9999 500
0x65 101 R E06
E1.06
P-Portion cur. contr. de- energization A --- 1300 9999 1300
0x66 102 R E076
E1.07
I-Portion cur. contr. De- energization A --- 500 9999 500
0x67 103 R/W E08 Ramp selection --- 1 2 1 0 = digital set v. (time constant)
1 = all set v. (rise constant.)
2 = selectable ramps
0x68
104
R/W
E09
Time delay enable signal
s
0
9999
0
1000 = 1.00s
