(3.0) Features
(3.1) Top Panel
1. Main Display
This full-color multi-touch display shows information relevant to HeadRush Core’s current operation. Touch the
display (and use the hardware controls) to control the interface. See (4.1) Main Screen to learn how it works.
2. Encoder
Turn this encoder to scroll through the available menu options or adjust the parameter values of the selected
field in the display. Push the encoder to confirm your selection.
3. Footswitches
Press these footswitches to activate or deactivate the assigned block or scene, or to load the assigned rig. See
(4.5) Footswitch Modes for more information.
4. Footswitch Indicators
These lights indicate whether the block, rig, or scene assigned to each footswitch is on (brightly lit) or off (dimly
lit).
5. Main Volume
Turn this knob to adjust the volume level of the Outputs.
6. Headphone Volume
Turn this knob to adjust the volume level of the Phones Output.
2
1
3
