Teach-in | Drilling and milling patterns
5
412
HEIDENHAIN | MANUALplus 620 | User's Manual | 12/2017
Linear hole pattern on lateral surface
A linear hole pattern is to be machined on the lateral surface of the
workpiece with the Drilling axial cycle. This machining operation
requires a traversable spindle and driven tools.
The drilling pattern is defined by the coordinates of the first hole,
the number of holes, and the spacing between the holes. Only the
depth is indicated for the drilling cycle.
Tool data
TO = 2 – Tool orientation
DV = 8 – Drilling diameter
BW = 118 – Point angle
AW = 1 – The tool is a driven tool
