TECHNICAL DETAILS
1-1MS 3000 • 9095-032A
1. TECHNICAL DETAILS
1.1 General
Note:
The details are based on standard applications. In special situations, it may be possible
to deviate from these. This may only be done with the prior written approval of the
supplier.
For accessories and options see the accessory book.
Description MS 3000
Platform length (A) [m] 8.5 - 15
Platform width [m] 1.5 - 2.5
Distance between mast centres (B) [m] 6.9
Max. anchor distance [m] 6
Max. mastheight free-standing (C) [m] 8
Max. mastheight anchored (C) [m] 100
Max. mastheight above last anchor [m] 0
Mast type DRK500
Max. number of persons 3
Platform speed [m/min.] 4.7
Loading capacity [kg] see section 1.4
Height of first anchor [m] 8
