CONTROL COMPONENTS
5-1
MS 3000
•
9095-032A
5
.
CONTROL COMPONENTS
5.1
Power supply socket for the
platform
The power supply cable for the electrical
supply between the building site
connection and the mast climbing work
platform must be connected to the socket.
The connection socket is positioned in the
centre of the platform. See chapter 1 for
the cable specifications.
Fig.5-1
Platform power supply socket
28
30
