ASSEMBLY AND ANCHORING

6-14 MS 3000 • 9095-032A

Fig.6-19 Lightning protection

Fig.6-18 Adjusting EMOS

6.7 Adjusting the EMOS system

1. The switch can only been turned

with the correct key. Set the EMOS

switch (1,2,3) in position 2. The

config panel starts to flash.

2. The program can be changed with

the UP or DOWN button on the

control box.

3. Set the desired program

(See chapter 1.4).

4. Set the EMOS switch on position 1.

5. The config panel shows the

adjusted value.

6. Remove the key.

6.8 Lightning protection

1. Mount the connection between the

chassis and the earth. This

connection must satisfy the

following specification:

DIN VDE 0185, part II, §5.2

The cable supplied (25 mm² cross

section, 25 m long) must be

connected to the terminal box on

the building site.
