TRANSPORT
4-3
MS 3000 • 9095-032A
No. of basic machines x 4415 =
No. of platform elements 150 x 198 =
No. of platform elements 175 x 205 =
No. of mast elements 150 x 86 =
No. of plug-in fences 150 x 16,2 =
No. of plug-in fences 175 x 18,2 =
No. of end fences x 32 =
No. of gates x 17,1 =
No. of lengthwise posts x 3,2 =
No. of gate side posts x 3,4 =
No. of end fence posts x 4,0 =
Total transport weight = kg
+
4.2 Repositioning with a crane
During movement there may be
no load on the platform.
At the building site the mast climbing
work platform can be repositioned with a
crane under the following circumstances.
A maximum of 4 mast elements may be
mounted on the chassis or the ground
frame. The eye hooks of the crane can
be attached to lifting points of the
chassis.
The total transport weight can be
calculated on the undermentioned way.
