TECHNICAL DETAILS
1-3MS 3000 • 9095-032A
Meaning of the letters page 2-1:
A = Platform element 150
B = Platform element 175
C = Plug-in fence 175
D = Plug-in fence 150
E = End fence
F = Gate
G = Lengthwise post
H = Gate side post
I = End side post
J = Mast element 150
Part l x b x h [mm]
weight
[kg]
No. of
bolts
bolt dim.
& quality
torque
[Nm]
other
Basic machine 8.5 m 8500x2350x1920 4415 --- --- ---
Max. platform
extension façade
side 1000 mm
Mast element 150 1508x570x565 86 4
M16 x 150
qual. 8.8
150 Module 8
Platform element 150 1500x1500x500 198 --- --- ---
Max. platform
extension façade
side 1000 mm
Platform element 175 1750x1500x500 205 --- --- ---
Max. platform
extension façade
side 1000 mm
Plug-in fence 150 1425x30x1080 16.2 --- --- --- ---
Plug-in fence 175 1605x30x1080 18.2 --- --- --- ---
End fence 3000x30x1080 32.0 --- --- --- ---
Gate 1605x30x1080 17.1 --- --- --- ---
Lengthwise post 1195x45x120 3.2 --- --- --- ---
Gate side post 1210x110x120 3.4 --- --- --- ---
End side post 1245x118x100 4.0 --- --- --- ---
