DISASSEMBLY AND TRANSPORT
8-2 MS 3000 • 9095-032A
Fig.8-2 Locking pin outrigger
Fig.8-3 Locking pin outrigger chassis
There are two possible ways to transport
the basic machine. This can be done with
or without the platform elements being
attached. The transport method depends
on the dimensions of the platform and the
widths and lengths of vehicles permitted by
national regulations.
If the basic machine is too large to be
transported in one piece, take the following
steps.
10. Disassemble the fencing, the fence
posts, the access gate and the
gateposts.
11. Disassemble the platform
extensions. Slide in the outriggers
and secure them.
12. Disassemble the platform elements.
13. Slide in the outriggers of the chassis
and secure them.
