MALFUNCTION ANALYSIS
10-2 MS 3000 • 9095-032A
In all cases not covered by the above malfunction tables an electrician must be
consulted.
No power supply
- Defective fuses in building site
supply
- Damaged cable
- Motor safety relais switched off
- Main switch defective
Voltage too low
- Incorrect cable type
- Cable is too long
Motor does not run
42 Vac control voltage not present - Automatic fuses operated
Voltage present but
platform cannot be
raised or lowered
Relays K102 en K103 are energized
but platform does not move up or
down
- Motor brake locked
- Adjust brake
Brake distance too long - Adjust brake
Other malfunctions
The platform does not develop
sufficient power
- Inform your technical service or
dealer
