HERO MAESTRO EDGE PROGRAMMED FI - Front Cover and Floor Side Covers Removal

35
(8) Bolts
•
Remove the bolts (8).
•
Remove the screws (9) from left and right
side of the body cover.
(9) Screws
•
Remove the body cover bolts (10).
(10) Body cover bolts
•
Remove the fuel filler cap (page 20).
• Disconnect the fuel tank lid lock cable (11).
10
(11) Fuel tank lid lock cable
11
8
9
