36
(12) Tail/stop lamp connector
•
Disconnect the tail/stop lamp connector
(12).
12
•
Release the body cover from its frame.
•
Pull the body cover slightly backwards and
release the tabs (13) from it slots (14)
from both sides of the vehicle.
(13) Tabs (14) Slots
13
14
•
Disconnect the drain tube from the joint
(15).
(15) Drain tube
15
