15
ODOMETER / TRIPMETER
The odometer (1) shows accumulated
distance traveled.
Tripmeter displays upto 999.9 kms. If the
tripmeter exceeds "999.9" kms it will return
to "0.0" kms automatically.
When tripmeter is selected long press the
reset button (3) to reset tripmeter to zero.
The odometer displays from "0 to 999999"
kms.
The tripmeter (2) shows distance traveled
since trip meter was reset last time.
The approximate amount of fuel quantity
available in the fuel tank is indicated by
the number of vertical bars in the display.
Each segment display approx. 0.5 litres of
fuel.
The fuel gauge (1) is of a Liquid Crystal
Display (LCD) type.
If all the vertical bars (2) are displayed it
means fuel quantity in the fuel tank is 5.3
litres.
If only one vertical bar is displayed and
blinks, this indicates that the fuel quantity
is low and the fuel tank should be refilled
as soon as possible.
LCD PANEL FUEL GAUGE
km/h
0
20
40
60
80
100
km
km
F
E
ODO
TRIP
RESET
SERVICE DUE
1
2
3
(1) Odometer
(3) Reset button
(2) Tripmeter
2
(1) Fuel gauge (2) Vertical bars
1
