3. Disconnect the rear turn signal lamp
connectors and tail/stop lamp connector.
4. Remove the wire from wire band (1).
5. Remove the body cover.
Installation is in the reverse order of
removal.
Installation:
Front Center Cover
1. Remove the two screws (1) on the inner
cover side.
Removal:
2. Remove the two screws (2) near the
front fender.
(1) Wire band, Cover connector
(1) Screws
1
(2) Screws
2
1
Combined
Braking System
