HERO MAESTRO - Body Cover

4. Remove front bolt (3) and screws (4).
above the luggage hook.
5. Remove the luggage hook screws (5).
6. Remove the screw (6) located slightly
Body Cover
Installation:
2. Lift up the body cover (page 33) and
detach the seat cable from the seat catch
bracket.
7. Remove the center compartment.
Installation is in the reverse order of
removal.
1. Open the seat (page 30)
Removal:
34
(1) Screws (2) Bolts
2
1
(3) Front bolt (4) Screws
3
(5) Luggage hook screws (6) Screw
6
5
4
