removing the screws (2).
Refer to the Safety Precautions (page 51).
The air cleaner should be replaced at
regular intervals (page 52-54). Replace
more frequently when riding in unusually
wet or dusty areas.
AIR CLEANER
1. Lift up the body cover (page 32).
2. Remove the air cleaner cover (1) by
(1) Air Cleaner Cover
(2) Screws
3. Remove the air cleaner element (3)
by removing the screw (4).
(3) Air Cleaner Element (4) Screw
4. Clean the air cleaner housing using a
shop towel.
(5) Air cleaner housing
55
Do not Clean Air filter.
Replace it, According to
Maintenance Schedule.
1
2
3
4
35
Install a new air cleaner element in the
reverse order of removal.
