IGNITION SWITCH
ESSENTIAL INDIVIDUAL
COMPONENTS
The ignition switch (1) is on the right side
below the steering.
"ON" Position
"OFF" Position/
Lock open
“LOCK” Position
2. Ignition key
1. Ignition switch
3. Steering lock position
27
3
2
1
"ON"
"OFF"
The LCD panel illuminates & initial display of
multi function digital segments are displayed.
The speedometer needle swings to the
maximum scale once and back to its normal
position. The engine can be started. Turn
signal lamp, Horn, Tail / Stop lamp, Fuel
gauge and Position lamp will be functional.
Key cannot be removed
"LOCK"
Engine cannot be started. Horn, Turn signal
lamps and Tail /Stop lamp cannot be operated.
Key can be removed
Steering can be locked
Key can be removed
