BULB REPLACEMENT
Be sure to turn the ignition switch
OFF when replacing the bulb.
Do not use bulbs other than that
specified.
Do not put finger prints on the headlamp
bulb, as they may create hot spots on the
bulb and cause it to break.
Wear clean gloves while replacing the
bulb. If you touch the bulb with your bare
hands, clean it with a cloth moistened with
alcohol to prevent its early failure.
Refer to the Safety Precautions (page 51).
The bulb becomes very hot while the lamp
is ON, and remains hot for a while after it is
turned OFF. Be sure to let it cool down
before servicing.
After installing a new bulb, check
that the lamp operates properly.
1. Remove the headlamp case (page 38).
2. Remove the dust cover (1).
5. Install a new bulb in the reverse
order of removal.
3. Remove the bulb (2) pressing down
the clip (3).
Headlamp Bulb
4. P u l l o u t t h e h e a d l a m p b u l b
without turning.
(1) Dust cover (2) Bulb (3) Clip
66
1
2 3
