Tail / stop lamp Bulb
1. Insert hand from body cover rear side,
above rear fender area and remove
tail/stop lamp bulb holder (1) by turning
counterclockwise.
3. Install a new bulb in the reverse order of
removal.
67
1
(1) Bulb holder
2. Remove the bulb (2) from bulb holder
by pressing in and turning counter
clockwise.
(1) Bulb holder (2) Bulb
Front Turn Signal Bulb
1. Remove the front cover (page 36).
2. Remove the bulb holder (1) by turning
counterclockwise.
(1) Bulb holder
1
1
2
