The Odometer (1) shows accumulated distance
traveled.
Push the Mode button (4) to select Odometer,
Tripmeter-A or Tripmeter-B. Tripmeter-A
ODOMETER/TRIPMETER
The Tripmeter shows distance traveled since
trip meter was reset last time. There are two
tripmeters, Tripmeter-A (2) and Tripmeter-
B (3).
· The time advances by 1 minute, each
time the button is pressed.
· The time advances fast when the button is
pressed and held.
î To end the adjustment press Set Button
(2). The display will stop flashing
automatically and the adjustment will be
saved or if the button is not pressed for
about 30 seconds.
The clock will reset " " if the battery is
disconnected.
NOTE
AM :
km.
TOTAL
km..
TRIP A
km..
TRIP B
1
2
3
4
5
6
11
7
8
9
10
x1000rpm
MODE
SET
km/h
AM
km
TRIP
A
E
F
4
5
3
1
2
SERVICE REMINDER INDICATOR
The indicator shall start blinking when the
vehicle covers kilometers as specified in the
maintenance schedule. The indicator will keep
on blinking throughout the kilometer interval
for a particular service and will stay “ON”
thereafter.
The Odometer can be displayed from "0 to
999999" kms.
When Tripmeter is selected long press the Set
button to reset Tripmeter to zero.
or Tripmeter-B can be displayed upto
99999.9 kms. If the Tripmeter exceeds
"99999.9" kms it will return to "0.0" kms
automatically.
The Service Reminder Indicator (5) is to
indicator to an user to bring the vehicle to an
Authorised Hero MotoCorp workshop for service.
The Service Reminder Indicator can be reset
at an Authorized Hero MotoCorp workshop.
LEFT HANDLEBAR CONTROLS
3
1
2
4
13
