HERO XTREME - Motorcycle Views

(13) Service reminder indicator
(1) Turn signal switch
(2) Horn switch
(3) Headlamp dimmer switch
(4) Clutch lever
(5) Passing switch
(6) Rear view mirror
(7) Choke lever
(8) Set button
(9) Immobilizer malfunction indicator
(10) Neutral indicator
(11) Tachometer
(12) Side stand indicator
(14) Turn signal indicator
(15) High beam indicator
(16) LCD panel
(17) Mode button
(18) Front master cylinder
(19) Front brake lever
(20) Headlamp switch
(21) Throttle grip
(22) Starter switch
(23) Ignition switch with Immobilizer
(24) Leg guard
(25) Fuel tank cap
*Accessories and features shown may not be part of standard fitment.
MOTORCYCLE VIEWS
TOP VIEW
7
1
6
3
2
4
5
11 14
13
12
8
9
10
15
7
16
17
18
19
20
21
22
23
24
25
