HERO XTREME - Page 11

(6) Rider foot rest
(3) Starter motor
(2) Fuel valve
(5) Main stand
(1) Air suction valve
(4) Gear shift pedal
(8) Pillion foot rest
(7) Side stand
(11) Rear grip
(9) Women pillion step (Optional)
(10) Saree guard
(12) Side cover left
(13) Side stand switch
(14) Front visor
(15) Headlamp
(16) Front left turn signal lamp
(17) Front fender
(18) Side reflex reflector
*Accessories and features shown may not be part of standard fitment.
LEFT SIDE VIEW
