HERO XTREME - Page 12

(1) Rear disc (Optional)
(2) Battery compartment (inside)
(3) Rear master cylinder (Optional)
(4) Brake pedal
(6) Kick starter pedal
(7) Carburetor
(5) Oil level dipstick
(9) Front disc
(8) Front caliper assembly
(10) Rear brake fluid
(12) Fuse box/Document &
(11) Seat
reservoir (Optional)
Tool kit compartment
(14) Rear reflex reflector
(13) Tail/stop lamp
(16) Licence plate lamp
(15) Right rear turn signal lamp
(17) Rear caliper assembly
(Optional)
(18) Exhaust muffler
*Accessories and features shown may not be part of standard fitment.
9
MOTORCYCLE VIEWS
RIGHT SIDE VIEW
1
2
3
4
5
6
7
8 9
10
11
12
13
15
14
16
17
18
