Always apply front and rear brakes
simultaneously to avoid skidding of vehicle.
WARNING
1
1
(1) Wear Indicator Grooves
REAR BRAKE
Drum type
î Measure the distance brake pedal (1)
moves before the brake starts to take hold.
î Park the motorcycle on its main stand.
If proper adjustment cannot be obtained by
this method, visit your Authorised Hero
MotoCorp workshop.
NOTE
1
2
(1) Rear brake pedal (2) Free play 20-30 mm
î Make sure that the cut-out on the adjusting
nut is seated on the brake arm (4) after
î Apply the brake several times and check for
free wheel rotation when released.
the final adjustment has been made.
Free play (2) should be 20-30 mm.
î If adjustment is necessary, turn the rear
brake adjusting nut (3).
(3) Adjusting nut (4) Brake joint pin
3
4
(A) Cut-out not seated (B) Cut-out seated
3
4
A
B
3
4
(A) Decrease free play (CW)
(B) Increase free play (ACW)
43
