V-Switch quad II - Installation and Operation Manual
ON SCREEN DISPLAY
16
QUAD MODE
Use arrow keys to navigate in the SYSTEM menu to the entry QUAD MODE and press ENTER/SELECT
to open the QUAD MODE window.
Channel selection timeout defines the period (1 to 30 seconds) after which the selector will close automatically.
Default setting is 5 seconds.
Selector
In Quad mode, use hotkey ‘Q’ to open the selector.
The selector indicates the active channel (mouse and
keyboard enabled). Alternatively, press front button „Quad”.
Press hotkey + arrow key to switch the selector (active channel)
from one channel to the next.
After expiry of the selector timeout, the selector closes.
OSD - SYSTEM - QUAD MODE
