V-Switch quad II - Installation and Operation Manual
ON SCREEN DISPLAY
33
FACTORY RESET
Use arrow keys to navigate in the CONFIGURATION menu to the Factory Reset and press ENTER/SELECT to
open the DEFAULTS window.
Use this function to reset the current settings of V-Switch quad II to the factory default configuration. All four
input EDIDs are also reseted to their default values.
If necessary, save your current settings before using the DEFAULTS command. Execution of this command
results in a complete reset and reboot of V-Switch quad II with factory defaults.
FACTORY DEFAULTS:
SYSTEM HOTKEY = Multiple Hotkey / Hotkey = Ctrl + Alt
HOTMOUSE = ON / Hotmouse timeout = 5 sec.
QUAD MODE = Channel selection timeout = 5 sec.
OSD POSITION = centered
OSD LANGUAGE = English
SECURITY = None (security level = 0)
DISABLE CHANNEL = All four channels are active
CONTROL = Off
MODE PIP = Size = 15 % Zoom factor = 1
Display mode = triple Active channel = gap;
Offset from top = 0 %
Start configuration = Quad / active channel = 1
CONSOLE VIDEO OUTPUT = auto
KEYBOARD = English
TOUCHSCREEN = Mouse emulate right click / Quad remains / PiP switches
FADE = Off
MULTI MONITOR = Monitor 1 --> Channel 1; Monitor 2 --> Channel2;
Monitor 3 --> Channel 3; Monitor 4 --> Channel4;
VIDEO VIDEO INPUT = DVI / VGA (all channels)
BRIGHTNESS = +0 (all channels)
CONTRAST = 56 % (all channels)
HORIZ POSITION = auto (all channels)
VERT POSITION = auto (all channels)
SCREEN WIDTH = +0 (screen-width correction of all channels)
PHASE = +0 (all channels)
FORMAT Fit to screen = No (all channels)
COMPUTER MOUSE USB mouse positioning = relative (all channels)
EDID / DDC 1600x1200@60, 1920x1200@60, digital
USB DEVICE 1-4 = Off / manual switching w. warning / name: Device 1 (-4)
OSD - CONFIGURATION - FACTORY RESET
