V-Switch quad II - Installation and Operation Manual
ON SCREEN DISPLAY
46
KEYBOARD
Use arrow keys to navigate in the COMPUTER menu to the entry KEYBOARD and press ENTER/SELECT
to open the KEYBOARD window.
Use this display feature to identify which keyboard type (USB, PC1, PC2 or PC3) has been recognized at
which computer port.
MOUSE
Use arrow keys to navigate in COMPUTER menu to the MOUSE line and press ENTER/SELECT to open the
MOUSE window.
The upper half of the MOUSE window shows which mouse type (USB, PS/2 or PS/2 wheel) has been
recognized at which computer port.
USB – mouse positioning
For USB ports, you may specify absolute or relative mouse positioning.
Choose absolute mouse positioning if a device is connected to the console that supports absolute coordinates,
such as graphic trays, screen pads or KVM extenders (HETEC V-Trans I or V-IP).
OSD - COMPUTER - KEYBOARD / MOUSE
