V-Switch quad II - Installation and Operation Manual
ANNEX
68
Settings
Click the „device configuration” button to open the SETTINGS window. It allows you to set the font size for
the OSD window, log parameters, and the COM port V-Switch quad II is connected to.
Remote OSD operation
Click the green arrow to open the On Screen Display (OSD) of V-Switch quad II remotely on your
external Windows computer.
Now, the main OSD menu is open and ready
for navigation.
Navigation
Use arrow keys on the keyboard of your remote
Windows computer to navigate to the desired line
in the OSD menu and confirm by pressing ENTER.
Use the ESC key to return to the previous menu.
DEVICE CONFIGURATION PROGRAM
