TT80, TT90 and TT90-UPC
Deviation span of indication (at 20° C, rel. humidity 50%)
– Analogue output ≤ 0,3 %
– Analogue indication ≤ 2 %
– Analogue indication and digital output :
TT80 and TT90 ≤ 0,15 % + 0,05 µm
TT90-UPC ≤ 0,15 % + 0,01 µm
For TT90-UPC, the probe needs to be adjusted on the instrument to reach the performance
of 0,0115 µm within the range of ±0,5 µm.
Hysteresis
– Indication —
– Classification signals —
Drift of zero point (at 20°C, rel. humidity ≤ 50%) ≤ ± 0,005 % / °C
Drift of probe sensitivity (at 20°C, rel. humidity ≤ 50%) ≤ ± 0,005 % / °C
Drift of saved values 0 %
Response time
– Analogue indication ≤ 100 ms
– Numerical indication ≤ 100 ms
– Output, relative to analogue indication ≤ 30 ms
– Value classification ≤ 100 ms
– Digital output series ≤ 100 ms
Holding time for numerical indication 100 ms
(Not applicable to TT90-UPC)
Frequency limit (relative to signal input)
– Analogue indication —
– Numerical indication 10 Hz
– Analogue output 10 Hz
– Analogue indication 10 Hz
– Value classification 10 Hz
– Memories 10 Hz
Analogue output
– Voltage range ± 2V / ± 10V
– Output current max. 2mA
– Sensitivity see instruction manual
– Permissible load impedance ≥ 5 k Ω
– Residual ripple (probe at zero value) ≤ 1 mV
– Reference voltage level analogue earth (0 V)
