4
TT90 only :
– 1 Set of accessories for TESA UPC 05960039
consisting of :
• 1 Opto-RS cable, bidirectional 04761049
• 1 Opto-RS interface to RS232 04760087
• 1 Connecting cable for the vacuum pump 04761070
Switchable measruing ranges / Numerical interval / Scale interval.
The TT90 and TT90-UPC measuring range is limited to ±200 µm/0.008 in. However, the
ranges from 500 up to 5000 µm/0,02 to 0.2 in can additionally be used for displaying the
measured value. In the chart below, there is no relationship between the right-hand (µm)
and left-hand columns (in).
If the probes are mixed in a combination (+A+B or –A-B), the numerical value can be as
high as 9999,9 µm or 0.4 in.
TT80 and TT90 in TT80 mode
± 5000 µm / 0,01 µm / 200 µm
± 2000 µm / 0,01 µm / 100 µm
± 500 µm / 0,01 µm / 20 µm
± 200 µm / 0,01 µm / 10 µm
± 50 µm / 0,01 µm / 2 µm
± 20 µm / 0,01 µm / 1 µm
± 5 µm / 0,01 µm / 0,2 µm
± 2 µm / 0,01 µm / 0,1 µm
± 0,5 µm / 0,01 µm / 0,02 µm
± 0.200 in / 0.000001 in / 0.010 in
± 0.100 in / 0.000001 in / 0.005 in
± 0.020 in / 0.000001 in / 0.001 in
± 0.010 in / 0.000001 in / 0.0005 in
± 0.002 in / 0.000001 in / 0.0001 in
± 0.001 in / 0.000001 in / 0.00005 in
± 0.0002 in / 0.000001 in / 0.00001 in
± 0.0001 in / 0.000001 in / 0.000005 in
± 0.00002 in / 0.000001 in / 0.000001 in
3 TECHNICAL SPECIFICATIONS
If the tool operates in µin, the numerical value can be as high as 8000 µin.
TT90 and TT90-UPC
± 5000 µm / 0,001 µm / 100 µm
± 2000 µm / 0,001 µm / 20 µm
± 500 µm / 0.001 µm / 10 µm
± 0.100 in / 0.000001 in / 0.005 in
± 0.020 in / 0.000001 in / 0.001 in
± 0.010 in / 0.000001 in / 0.0005 in
± 200 µm / 0,001 µm / 10 µm
± 50 µm / 0,001 µm / 2 µm
± 20 µm / 0,001 µm / 1 µm
± 5 µm / 0,001 µm / 0,2 µm
± 2 µm / 0,001 µm / 0,1 µm
± 0,5 µm / 0,001 µm / 0,02 µm
± 5000 µin / 0.05 µin / 200 µin
± 2000 µin / 0.05 µin / 100 µin
± 1000 µin / 0.05 µin / 50 µin
± 200 µin / 0.05 µin / 10 µin
± 100 µin / 0.05 µin / 5 µin
± 20 µin / 0.05 µin / 1 µin
