9.7 Analogue output
The analogue output is linked to the analogue indication for the measuring ranges of
± 5000 µm/± 0.020 in. Therefore, the voltage in full scale matches ± 2V/±10V.
For ranges of ± 200 µm/± 0.010 in, this output is the only one available with a voltage to
± 2V/±10V for a maximum value of ± 200 µm/0.010 in.
Ranges µm Voltage in full scale Sensitivity mV / µm
± 5000 ±2 V ±10 V 0,4 2
± 2000 ±2 V ±10 V 15
± 500 ±2 V ±10 V 4 20
± 200 ±2 V ±10 V 10 50
± 50 ±0,5 V ± 2,5 V 10 50
± 20 ±0,2 V ± 1 V 10 50
± 5 ±0,05 V ± 0,25 V 10 50
± 2 ±0,02 V ± 0,10 V 10 50
± 0.5 ±0,005 V ± 0,025 V 10 50
Maximum load capacitance: 40nF, max. 3mA.
For inch ranges, refer to chapter 6.3.
