December 2016 Page 2-7
PLT-01668, Version: 1.2 Setup and Installation Procedures
2.6 Connecting the Printer Power
To connect power to the printer, follow this procedure.
Note: Do not connect the printer’s USB cable until prompted during the printer driver installation.
1. Plug the AC adapter power cable into the back of the printer.
2. Plug the wall power cable into the AC power adapter.
3. Plug the wall power cable into a standard 100-240VAC power outlet.
4. Press the printer’s power button to power on the printer.
Note: The printer powers down during the “sleep time” but automatically powers up when a print
job is sent.
