December 2016 Page 4-35
PLT-01668, Version: 1.2 Printer Preferences
4.8 K Panel Resin Tab
Use the K Panel Resin tab to control where the resin black (K) Panel of a full-color ribbon is printed. If
a ribbon without a K resin panel is installed in your printer, these options are grayed out and
unavailable.
Note: Orientation of the card display area is determined by the orientation specified in the template.
See Section 4.7.1: Defining an Overlay or Print Area for information on the card size, etc.
Field Description
Print All Black with K Panel
Full Card Select this option to overlay and/or print the entire card.
Defined Area(s)
Select this option to overlay and/or print only in the selected and define area(s).
See Section 4.8.1: Defined Area.
Undefined Area(s)
Select this option to overlay and/or print in the space outside the selected and
defined area.
Print YMC under K Select this option to print all black in the designated areas with the yellow (Y),
magenta (M) and cyan (C) ribbon panels directly beneath the resin black (K) panel.
This combination provides a gradual transition between the resin black text or bar
code.
Print K Only Select this option to print using the resin black (K) panel onto a white background to
maximize the sharpness of printed text and bar codes.
