December 2016 Page 5-11
PLT-01668, Version: 1.2 System Overview - Troubleshooting
5.2.4.1 Additional Printer Specific Tools
Label Description
INFO
• Printer Type
• Firmware Version
• IP Address
• Flipper
• Lamination
• Magnetics
• E-Card
• Password
• Card count
TEST PRINTS
Color Photo: Select this to print a color card to test communication and integrity.
Alignment: Select this to print a card used to align the print image on the card.
Settings: Select this to print a card with the Advanced settings.
Resin: Select this to print a RESIN test card.
Rewritable: Select this to ERASE the Rewritable card.
Magnetic: Select this to test Magnetic encoding. (Hi-Co only)
Lamination: Select this to laminate a test card.
Hopper Select Ability to select which hopper to feed cards from. Applies to Dual Hopper Printers.
Toolbox
Clean Printer: Select this to run the clean printer routine.
Clean Laminator: Select this to run the clean laminator routine.
Calibrate Mag: Select this to calibrate the Magnetic Sensor
Calibrate Rib Sensor: Select this to calibrate the ribbon sensor.
Network: Select this to configure network options.
Language Select this choice to change the Printer Displayed Language.
Exit Select this choice to exit the Printer Tool options.
