Chapter 6. Parameter Setting
6-29
Menu Menu name Unit Display range Initial value Mode
tS-14 Auto Jog Time1 sec 1 ~ 50000 1
tS-15 Auto Jog Time2 sec 1 ~ 50000 2
tS-16 Auto Jog Time3 sec 1 ~ 50000 3
Input the auto jog mode set time in [sec].
Menu Menu name Unit Display range Initial value Mode
tS-17 Auto Jog Set 0, 1 0
Setting Auto Jog mode operation
0: Auto Jog mode not activated
1: Auto Jog mode activated (Motor starts running)
6.8.3 Simulation Mode (P6-03): Motorless operation
Operates just like when the motor is connected even when there is no actual motor.
Motor speed is displayed in the window at this time just as the motor is running at the
commanded speed.
This function enables indirect test of the wiring status between the current servo driver and the
upper controller before the motor is actually connected.
(Caution !) Menus marked with "*" cannot be corrected during Servo-On.
P6 – 03
↓
ENTER key (use only Mount Loader)
OFF
↓
UP key (Mount Loader), PROG key (Digital Loader)
ON
↓
ENTER key
P6 – 03
↓
Press UP key 2 times (Mount Loader), or press MODE key 2 times (Digital
Loader)
St --
↓
ENTER key (Mount Loader), PROG key (Digital Loader)
St – 01
Indicates virtual motor speed according to the conditions of the I/O
connected to CN1.
To Next Page
