Chapter 17. Specifications of options
17-1
17. Specifications of options
17.1 AC servo motor cable specifications
17.1.1 Encoder signal cable (Flange 60, 80 Series)
Order side( FCA_□□□□□)
Operating type Non-operatig type
Flange
3m 5m 10m 20m 3m 5m 10 20m
60,80 EA03F EA05F EA10F EA20F EA03N EA05N EA10N EA20N
17.1.2 Encoder singal cable (Flange 130,180 Series)
Order code( FCA_□□□□□)
Operating type Non-operating type
Flange
3m 5m 10m 20m 3m 5m 10 20m
130,180 FC03F FC05F FC10F FC20F FC03N FC05N FC10N FC20N
