CHAPTER 6
Troubleshooting
Studio Command Series User Manual 65
HEAD
TEMP
Fixture head temperature has exceeded the
maximum permissible level due to:
• a bad fan
• excessive ambient temperatures
• blockage in fan vents on back of the fixture
head
• a broken wire connecting the fan to the logic
board.
The fixture automatically turns the lamp and
motors off.
Reduce the ambient temperature around the
fixture and/or remove any blockage from the
fixture’s fan vents.
Contact High End Systems customer support
(see
page ii) if problem continues.
LAMP
LIFE
The fixture’s lamp life limitation setting was
enabled and the current lamp has exceeded
900 hours.
This message is only a warning. Take no
action unless this message changes to “LAMP
OUT.”
LAMP
MISS
The fixture cannot detect the temperature
readback from the thermometer in the fixture
head.
The lamp cap is not installed on the fixture.
There is a broken wire or loose connector
between the thermometer and the logic board.
The lamp interlock in the head has failed.
Make sure lamp cap is installed on the fixture
(see
Replacing the Lamp on page 58). The
lamp will not strike if the lamp plate is
removed. If the lamp is on when the lamp
plate is removed, the lamp is extinguished. If
the lamp was on when the lamp plate was
removed, the lamp strikes again 30 seconds
after the lamp plate is reinstalled.
Contact High End Systems customer support
if problem continues.
LAMP
OUT
The fixture’s lamp life limitation setting was
enabled and the current lamp has exceeded
1000 hours. The fixture can no longer strike
the lamp.
Replace the lamp (see
Replacing the Lamp
on page 58) and reset the lamp hours (see
Resetting Lamp Hours (L/RS) (Studio
Command 1200/700 models only)
on page
40).
LAMP
STAT
Because of an unexpected electrical event,
the fixture cannot determine the current status
of the lamp.
Home the fixture (see
Homing the Fixture
(HOME)
on page 33).
Contact High End Systems customer support
if problem continues.
LAMP
TOUT
The fixture has unsuccessfully attempted to
strike the lamp.
Allow the fixture to cool, then attempt to
manually strike the lamp (see
Turning the
Lamp On or Off (LAMP)
on page 33).
Replace the lamp (see
Replacing the Lamp
on page 58).
Contact High End Systems customer support
problem continues.
Display
Message
Problem Solution
