Digital Day & Night Vision Scope User Manual
8
3. Turn the IR torch battery cover anticlockwise to remove it, and thread
the IR torch through the bracket hoop, then turn the IR torch battery
cover clockwise to tighten it.
Figure 2-12 Thread the IR Torch
4. Tighten the screws to fix the IR torch.
Figure 2-13 Fix the IR Torch
Note

Rotate the lever to adjust the IR torch bracket. The lever would
disassemble if continuously rotating it anticlockwise. Turn the lever
clockwise to install it.

Please ensure the anti-slip pattern of the lever is outward when pressing
the lever.

Please purchase the IR torch bracket and IR torch separately.
2.5 Power On/Off
Power On
When the device is connected to cable or the battery is enough, hold to
power on the device.

Hikmicro ALPEX LRF 4K Series Specifications

General

Frame Rate	50 Hz
Laser Rangefinder	Yes
IP Rating	IP67
Sensor Resolution	384 × 288
Detection Range	1800m
Display	0.39 inch, OLED
Laser Rangefinder Range	1000 m
Battery Type	Rechargeable Li-ion Battery
Weight	Approx. 980 g
Operating Temperature	-30°C to 55°C
Storage Temperature	-30°C to 60°C
Objective Lens	50 mm
Battery Life	8 hours
