Hikmicro ALPEX LRF 4K Series - Mount Device on Rail

Digital Day & Night Vision Scope User Manual
5
Figure 2-2 Loosen the Cover
2. Insert the battery into the battery compartment with the positive mark
inward.
Figure 2-3 Insert the Battery
3. Turn the battery cover clockwise to tighten it.
Figure 2-4 Tighten the Cover
2.3 Mount Device on Rail
Steps
1. Unscrew the ring top with Allen wrench.
Figure 2-5 Unscrew the Ring Top
