Hikmicro ALPEX LRF 4K Series User Manual

Digital Day & Night Vision Scope User Manual
19
3.10 Set Pitch Scale
You can enable pitch scale to view the device inclination angle in the live
view.
Steps
1. Hold the wheel to show the menu.
2. Go to Advanced Settings, and select Function Settings.
3. Rotate the wheel to select , and press the wheel to enable the pitch
scale.
4. Hold the wheel to save and exit.
Figure 3-7 Pitch Scale

Hikmicro ALPEX LRF 4K Series Specifications

General

Frame Rate	50 Hz
Laser Rangefinder	Yes
IP Rating	IP67
Sensor Resolution	384 × 288
Detection Range	1800m
Display	0.39 inch, OLED
Laser Rangefinder Range	1000 m
Battery Type	Rechargeable Li-ion Battery
Weight	Approx. 980 g
Operating Temperature	-30°C to 55°C
Storage Temperature	-30°C to 60°C
Objective Lens	50 mm
Battery Life	8 hours
