Digital Day & Night Vision Scope User Manual
14
3 Image Settings
3.1 Adjust Diopter
Steps
1. Power on the device.
2. Open the lens cover.
3. Hold the device and make sure the eyepiece covers your eye.
4. Adjust the diopter adjustment ring until the OSD information or image is
clear.
Figure 3-1 Adjust Diopter
Note
When adjusting diopter, DO NOT touch the surface of lens to avoid
smearing the lens.
3.2 Adjust Focus
Steps
1. Power on the device.
2. Hold the device and make sure the eyepiece covers your eye.
3. Adjust the focus ring until the image is clear.
Figure 3-2 Adjust Focus
