Hikmicro ALPEX LRF 4K Series User Manual

Digital Day & Night Vision Scope User Manual
7
Figure 2-9 Tighten the Screws
Note

The ring may vary according to different models. Please refer to the
actual product.

Please purchase the ring separately.

Use lint-free cloth to clean the device base and the rail.
2.4 Install IR Torch
Steps
1. Open the IR torch bracket, and place the device in the IR torch bracket.
Figure 2-10 Open the IR Torch Bracket
2. Lock the lever by pressing it to fix the bracket as figure shows.
Figure 2-11 Lock the Lever

Hikmicro ALPEX LRF 4K Series Specifications

General

Frame Rate	50 Hz
Laser Rangefinder	Yes
IP Rating	IP67
Sensor Resolution	384 × 288
Detection Range	1800m
Display	0.39 inch, OLED
Laser Rangefinder Range	1000 m
Battery Type	Rechargeable Li-ion Battery
Weight	Approx. 980 g
Operating Temperature	-30°C to 55°C
Storage Temperature	-30°C to 60°C
Objective Lens	50 mm
Battery Life	8 hours
