For device with more than one camera channels, you can set one or more channels to take
recordings if needed.
For recording sengs, refer to Video Recording and Picture Capture .
9.2.6 Set Audible Alarm Output
When the device detects targets in the detecon area, audible alarm can be triggered as a
warning.
Steps
1.
Go to Conguraon → Event → Basic Event → Audible Alarm Output .
2.
Select an Alarm Type.
3.
Select Sound Type and set related parameters.
-
Select Warning and its contents. Set the alarm
mes you need.
-
Select Custom Audio. You can select a custom audio
le from the drop-down list. If no le is
available, you can click Add to upload an audio le that meets the requirement. Up to six
audio
les can be uploaded, and each audio le shall not exceed 512 KB.
4.
Oponal: Click Test to play the selected audio le on the device.
5.
Set arming schedule for audible alarm. See Set Arming Schedule for details.
6.
Click Save.
Note
The funcon is only supported by certain device models.
9.2.7 Set Flashing Alarm Light Output
Steps
1.
Go to Conguraon → Event → Basic Event → Flashing Alarm Light Output .
2.
Select a White Light Mode.
Mode
Descripon
Flashing Alarm triggers the light to ash for a certain duraon. Set the ashing speed in
Flashing Frequency.
Solid Alarm triggers the light to turn on for a certain duraon.
3.
Set the light acon duraon and the brightness.
Flashing
Duraon
The me period of light on or light ashing when one alarm happens.
Brightness
The brightness of the light.
4.
Edit the arming schedule.
5.
Click Save.
Thermal Opcal Bi-spectrum Network Camera User Manual
61

HIKVISION DS-2TD2608-2/QA/FP Specifications

General

Model	DS-2TD2608-2/QA/FP
Sensor Type	Thermal
Pixel Interval	17 μm
Aperture	F1.0
Image Sensor (Visible)	1/2.7" Progressive Scan CMOS
Alarm	1 input, 1 output
Focus	Fixed
Type	Bullet
Response Waveband	8 μm ~ 14 μm
Thermal Sensitivity	≤ 50 mK
Lens	2 mm
Image Enhancement	AGC, 3D DNR
Image Display	3D DNR
Video Compression	H.265/H.264
Audio Compression	G.711u/G.722.1/G.726/MP2L2
Protocols	TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
Network Interface	RJ45 10M/100M Ethernet
Audio	1 input, 1 output
Power	DC12V, PoE (802.3af)
Power Supply	12 VDC ± 20%, PoE (802.3af)
Operating Temperature	-30 °C ~ 60 °C (-22 °F ~ 140 °F)
Dimensions	221.2 mm × 94.9 mm × 82.5 mm
Weight	770 g
Human Temperature Measurement Range	30 °C to 45 °C (86 °F to 113 °F)
Human Temperature Measurement Accuracy	± 0.5 °C (± 0.9 °F)
