HIKVISION DS-9616NI-I8 User Manual

Network Video Recorder User Manual
108
Figure 10-3 Playback by Smart Search
Step 5 Set the rules and areas for smart search of line crossing detection, intrusion detection or motion
detection event triggered recording.
Line Crossing Detection
1) Click the icon.
2) Click on the image to specify the start point and end point of the line.
Intrusion Detection
1) Click the icon.
2) Specify 4 points to set a quadrilateral region for intrusion detection. Only one region can be set.
Motion Detection
1) Click the icon.
2) Hold the mouse on the image to draw the detection area manually.
3) Click Search to search the matched video and start to play it.
10.1.4 Play Custom Searched Files
You can play the files by custom search with different conditions.
Step 1 Go to Playback.
Step 2 Select a camera or cameras from the list.
Step 3 Click Custom Search on the left bottom to enter the Search Condition interface.
Step 4 Enter the search conditions for the files, e.g., time, file status, event type, etc.

HIKVISION DS-9616NI-I8 Specifications

General

Sequence mode	Yes
Internal memory	4096 MB
Number of users	128 user(s)
Maximum resolution	3840 x 2160 pixels
Alarm input channels	16
Internal memory type	DDR4
Throughput data rate	256 Mbit/s
Video input channels	16 channels
Alarm output channels	4
Supported resolutions	3840 x 2160, 2560 x 1440, 1920 x 1080, 1600 x1200, 1280 x 1024, 1280 x 720, 1024 x 768
Video formats supported	H.264, H.264+, H.265, MPEG4
Analog signal format system	NTSC, PAL
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
RAID levels	0, 1, 5, 10
HDD capacity	8000 GB
HDD interface	Serial ATA
Maximum storage capacity	- TB
Number of HDDs installed	-
Number of HDDs supported	8
Total installed storage capacity	16000 GB
Product color	Black
Rack capacity	2U
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	200 W

Weight and Dimensions

Depth	470 mm
Width	445 mm
Height	90 mm
