HIKVISION DS-9616NI-I8 - Call a Patrol

Network Video Recorder User Manual
74
Figure 6-9 Key Point Configuration
1) Configure key point parameters.
Preset: Determines the order the PTZ will follow while cycling through the patrol.
Speed: Defines the speed the PTZ will move from one key point to the next.
Duration: Refers to the duration to stay at the corresponding key point.
2) Click Apply to save the key points to the patrol.
Step 7 (Optional) Click to edit the added key point.
Figure 6-10 Edit Key Point
Step 8 (Optional) Select a key point and click to delete it.
Step 9 (Optional) Click or to adjust the key point order.
Step 10 Click Apply to save the patrol settings.
Step 11 Repeat steps 3-9 to set more patrols.
6.3.4 Call a Patrol
Purpose
Calling a patrol makes the PTZ move according to the predefined patrol path.
Step 1 Click on the quick settings toolbar of the PTZ camera’s Live View.
